Specifications |
Built/yard |
1974, conversion 2007 |
Classification |
Germanischer Lloyd + 100 A5 Dredger + MC, expired |
Dimensions |
117.50 x 19.00 x 9.00 m |
Hopper capacity |
approx. 5,500 m3, max. 5,760 m3 |
DWT |
approx. 8,280 tons |
Diesel engine(s) |
2 x MAK type 8M25, 2,500 kW/each |
Propulsion |
twin screw, controllable pitch propellers |
Bow thruster |
600 kW |
Generators |
2,625 kW |
Trailing pipe(s) |
2, make IHC, diam. 900 mm |
Dredging depth |
max. 35.00 m |
Dredge pump(s) |
2, make IHC, 4,000 kW |
Jetwater pump |
2, 650 kW/each |
Bottom doors |
2 x 10 |
Pump ashore installation |
yes, 800 mm pipe diam. |
